Bobrick B-39003 Recessed Folded Paper Towel Dispenser and Waste Receptacle

Bobrick B-39003 Recessed Folded Paper Towel Dispenser and Waste Receptacle

Bobrick TrimLineSeries™, Minimalistic Design Series

Recessed folded paper towel dispenser and waste receptacle is Type-304 stainless steel with all-welded construction; exposed surfaces have satin finish.
Unit is equipped with TowelMate consisting of a 90° return towel guide angle inside cabinet to prevent paper towels from falling forward out when door is opened for servicing and a Nylon Rod across the center of the towel tray to dispense paper towels one at a time.
Door is 18 gauge (1.2mm); has 9/16" (14mm) 90° return edges; secured to cabinet with a concealed, full-length, stainless steel piano-hinge and equipped with two tumbler locks keyed like other Bobrick washroom accessories.
Tumbler locks flush with the door, no protrusion.
Paper towel dispenser is equipped with a six-position adapter that is adjustable to dispense 600 C-fold, 800 multifold, or 1100 singlefold paper towels.
Waste receptacle is furnished with a removable, leakproof, rigid molded plastic waste-container with a minimum capacity of 12-gal. (45.4-L).

Waste Receptacle Capacity: 12 Gallons

Overall Dimensions: 17-3/16" Wide x 56" High, Projects 9/16" From Finish Face of Wall

Rough Wall Opening: 16" Wide x 54-5/8" High, 7-7/8" Minimum Recessed Depth

Replacement TowelMate® Accessory Module: Order Bobrick Part No. 39003-130

Replacement Lock and Key: Order Bobrick Part No. 39003-21

Replacement Waste Receptacle: Order Bobrick Part No. 39003-31

Skirt for Semi-Recessing: Order Bobrick Part No. 3949-57
